Unifreezing cooler

Unifreezing cooler

Internal length whole



~ 7960 mm



Internal width whole

~ 5340 mm

Height whole

~ 5860 mm



Housing

140 mm stainless steel floor panels

Front door

2 pieces

Entry height

~ 800 mm

Exit height

~ 4226 mm

Eject input

~ 970 mm

Exit output

~ 640 mm

The direction of movement of the tape



towering



System

0o

Number of levels

24



Clearance height

~ 135 mm

Maximum freezing time



65 minutes

Minimal freezing time

30 minutes

Tape material



stainless steel

Type

T304-26-0FP | 31

Tape width



26 "= 660 mm

Usable belt width



600 mm

Usable belt length

345 m + in / out section



Usable surface of the tape

207 m2 + entrance / exit section
